Size 29''

THIS PRO-LEVEL XC FLYER PAIRS NEW FLEXPOINT PRO REAR SUSPENSION WITH A SUPERLIGHT FULL COMPOSITE FRAME AND RACE-READY GEOMETRY. IT’S THE ULTIMATE WEAPON FOR TECHNICAL CROSS-COUNTRY TERRAIN.



KEY PERFORMANCE FACTORS



Ultra-efficient

Next-generation Advanced composite mainframe and rear swingarm is 250g lighter than previous version. The bottom bracket area is stiffer for faster acceleration, and a steeper seattube puts the rider in an efficient, front-forward climbing position.



Superior control

All-new FlexPoint Pro suspension delivers 100mm of smooth, active rear travel. The reengineered frameset features modern XC geometry including a slacker 67.5-degree headtube and 110mm suspension fork for technical descents.



29er stability and speed

Frame geometry and suspension are optimized for larger-diameter 29-inch wheels. A longer reach and updated cockpit including a 35mm composite handlebar and alloy stem further boost balance and stability on XC terrain.



Colours – Black Diamond / Carbon

Frame – Advanced-Grade Composite front and rear triangles, 100mm FlexPoint Pro suspension, 12x148mm thru-axle

Fork – Fox 34 Float SC Performance Remote, 110mm, FIT4 damper, Boost 15×110 Kabolt, 44mm offset, remote lockout, custom tuned for Giant

Shock – Fox Float DPS Performance Elite, 165/45, custom tuned for Giant

Handlebar – Giant Contact XC Flat, composite, 760x35mm

Grips – Giant XC Pro S:32mm, M:32mm, L:34mm, XL:34mmStemGiant Contact SL XC, 35mm S:60mm, M:70mm, L:70mm, XL:70mm

Seatpost – Giant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm M: 125mm travel / 30.9 x 395mm L: 150mm travel / 30.9 x 440mm XL: 150mm travel / 30.9 x 445mm

Saddle – Fi’zi:k Antares R7 with S-Alloy rails

Pedals – N/A

Shifters – Shimano Deore SLX M7100, 1×12

Front Derailleur – N/A

Rear Derailleur – Shimano Deore SLX RD-M7100

Brakes – Shimano Deore BR-M6100, hydraulic, Shimano RT-56 rotors [F]180mm, [R]160mm

Brake Levers – Shimano Deore BL-M6100

Cassette – Shimano SLX M7100, 10×51

Chain – KMC X-12

Crankset – Shimano SLX, 32t S:170mm, M:175mm, L:175mm, XL:175mm

Bottom Bracket – Shimano, press fit

Rims – Giant XCR 2 29 Carbon WheelSystem

Hubs – Giant XCR 2 29 Carbon WheelSystem

Spokes – Giant XCR 2 29 Carbon WheelSystem

Tires – Maxxis Recon Race 29×2.4, foldable, TLR, EXO, tubeless

Extras – tubeless prepared, 2.4″ max tire size, 34t max chainring size, Giant/MRP CS chain guide

Weight – The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
